Huawei MA5800-X17 Access Network SmartAX MA5800 Series Gpon OLT

Name: Huawei MA5800X17 Access Network SmartAX MA5800 Series Gpon OLT
Brand: HUAWEI
Price: 1 USD

China Huawei MA5800-X17 Access Network SmartAX MA5800 Series Gpon OLT wholesale

Brand Name : HUAWEI

Model Number : MA5800-X17

Place of Origin : CHINA

MOQ : 1pc

Payment Terms : T/T, Western Union, MoneyGram

Supply Ability : 500pcs/week

Delivery Time : 3-7 work days

Packaging Details : 1pc into a spare inner foam carton and pack with exteral wooden carton

Type : SDH/MSTP/PTN

Products status : Stock

Product name : Huawei MA5800-X17

Shipping term : DHL,Fedex,UPS,EMS,AIR

Condition : Brand New

Warranty : Six month

Contact Now

Huawei MA5800-X17 Access Network SmartAX MA5800 Series Gpon OLT

Product Description:

Instructions	MA5800-X17	MA5800-X15	MA5800-X7	MA5800-X2
Width x Depth x Height (mm)	11U high, 21 inches wide Without the mounting brackets: 493x287x486 With a lug: 535x287x486	11U tall, 19 inches wide Without hanging ears: 442x287x486 With a lug: 482.6x287x486	6U tall, 19 inches wide Without hanging ears: 442x268.7x264 With IEC mounting ears: 482.6x268.7x264 With ETSI mounting brackets: 535x268.7x264	2U tall, 19 inches wide Without the mounting brackets: 442x268.7x88 With IEC mounting ears: 482.6x268.7x88 With ETSI mounting brackets: 535x268.7x88
Max. weight (with mounting ears)	45kg	35kg	26kg	9.4kg
Backplane bus switching capacity	10.5 Tbit/s	9.36 Tbit/s	4.68 Tbit/s	1.6 Tbit/s
Max. bandwidth per slot (load sharing mode)	H901MPLA/H901MPLC:100 Gbit/s H901MPLB:200 Gbit/s			H901MPSC:80 Gbit/s
System reliability index	Typical Configuration System Availability:> 99.999% System Mean Time Between Failures MTBF (Year): ≈45 Description: The MTBF time reference value of the MA5800 is 45 years, and the average repair time of the field replaceable unit (FRU) is 2 hours because of the difference between the networking environment and the board used by the device. Here is only a reference value, if you need more detailed information, please contact Huawei Technologies Co., Ltd. related personnel to provide
GPON edge number	272	240	112	32
10 G GPON port number	136	120	56	16
EPON port number	272	240	112	32
10 G EPON port number	136	120	56	16
GE/FE port number	816	720	336	96
10GE port number	136	120	56	16
E1 port number	544	480	224	64

Product Details:
Huawei MA5800-X17 Access Network SmartAX MA5800 Series Gpon OLT

Huawei MA5800-X17 Access Network SmartAX MA5800 Series Gpon OLT

If you are interested, please let us know the specific model. We will provide the best service and the best price!
